The modular design makes the system futureproof: ZEISS ACCURA can be modified to meet changing requirements on the configuration, sensors, and software.

Made for high temperatures

ZEISS ACCURA bridge is covered with Foam Insulating Technology, a new type of high-performance insulation. The housing covers ensure maximum insulation and minimal thickness. This enables the operator to select a measuring lab temperature between 20ºC and 26ºC.

Low weight, high dynamics

Made of steel and aluminum, the ZEISS ACCURA bridge is extremely rigid, yet slim. The aluminum elements are coated with CARAT technology from ZEISS to improve temperature stability and service life. The reduced weight of the moving parts improves the dynamic rigidity of the machine.

Futureproof

Thanks to its modular design, ZEISS ACCURA is ready to meet the demands of the future. It grows with your requirements on equipment, sensors and software.

Pre-wiring for contact and optical sensors, as well as scanning, makes ZEISS ACCURA immediately multisensor capable.

Maintenance-friendly design

All housing panels of the bridge can be removed and remounted in only a few steps. This reduces the time needed for maintenance and increases machine availability.

Optional High-dynamic Package

The High-dynamic Package turns ZEISS ACCURA into a high-speed measuring machine. It permits travel speed of up to 800 mm/s. Due to the high speed, the measuring area of the machine requires added protection.

Laser scanners monitor the protection zone around the machine. If anyone enters the safety zone, ZEISS ACCURA immediately slows down. High-speed measuring operations are automatically restarted once the zone is cleared. This safety technology is included with the High-dynamic Package.

VAST navigator

ZEISS ACCURA comes standard with VAST navigator technology to enable even faster calibration, approach and scanning, as well as improved precision.

Measuring accuracy into the corners

Every size of the ZEISS ACCURA comes with a maximized measuring range. This guarantees measuring accuracy into the corners.

Quality assurance with ZEISS ACCURA

Doppelmayr/Garaventa Group

https://www.youtube-nocookie.com/embed/GEj21kT4n2g?enablejsapi=1&showinfo=0&rel=0

With this particularly precise measuring machine, we also want to impress upon our entire team that we have to deliver 100 percent quality in everything we do.  Roland Schedler, Quality Assurance at Doppelmayr

The bridge-type measuring machine at a glance

Temperature independence

• High-performance isolation on the bridge for maximum effect
• CARAT guiding technology for high dynamics and performance

Future-proof and high-quality

• High degree of flexibility when choosing the sensor
• Glass ceramic scales for high accuracy and temperature stability
• Air bearings for high accelerations and performance

Ergonomically-correct work

• Ergonomically-correct work
• Touchscreen operation
• Stylus changer rack
• Wireless control panel

Additional components

• Rotary tables for optimizing the measuring range
• Pneumatic vibration insulation to prevent the need for an expensive foundation
• ZEISS AirSaver to reduce operating costs

Technical data for ZEISS ACCURA

Measuring accuracy with ZEISS probe system

	ZEISS VAST gold / ZEISS VAST XT gold / ZEISS VAST XTR gold
Measuring range X/Y/Z	length measurement error E0 in μm
9/12/8 – 9/16/8	1.2 + L/350
12/18/8 – 12/24/10	1.8 + L/350
12/30/10 – 12/42/10	1.9 + L/300
16/24/10 – 16/42/10	2.4 + L/300
16/24/15 – 16/42/15	3.2 + L/300
20/24/15 – 20/42/15	3.6 + L/300

	ZEISS VAST XXT
Measuring range X/Y/Z	length measurement error E0 in μm
9/12/8 – 9/16/8	1.6 + L/350
12/18/8 – 12/42/10	2.2 + L/300
16/24/10 – 16/42/10	3.4 + L/250
16/24/15 – 16/42/15	4.2 + L/250
20/24/15 – 20/42/15	4.9 + L/200
